| Frame |
Alpha Silver Aluminium, internal routing, chainstay disc-brake mount, rack and kickstand mount, 135×5 mm QR
|
| Rear Shock |
SR Suntour XCE 28, coil spring, preload, G2 Geometry w/51 mm offset on 29ers, 10
|
| Fork |
SR Suntour XCE 28, coil spring, preload, G2 Geometry w/51 mm offset on 29ers, 100 mm trave
|
| Head Set |
1-1/8˝ threadless, semi-integrated, semi-cartridge bearings
|
| Stem |
Bontrager alloy, 31.8 mm, 7-degree, Blendr compatible
|
| Handle Bars |
Bontrager alloy, 31.8 mm, 5 mm rise, 720 mm width (13.5: 690
|
| Tape Grips |
Bontrager XR Endurance Comp
|
| Brakes |
Tektro HD-275 hydraulic disc (13.5 & 15.5: Tektro HD-276 short reach lever)
|
| Tyres |
Bontrager XR2, 29×2.20˝ front, 29×2.0˝ rear (13.5 & 15.5: 27.5×2.20˝)
|
| Front Derailleur |
Shimano Tourney TY300
|
| Rear Derailleur |
Shimano Tourney TY300
|
| Shift Levers |
Shimano Altus M310, 7-speed
|
| Cassette |
Shimano HG200, 12-32, 7-speed
|
| Crankset |
Shimano Tourney TY301, 42/34/24
|
| Bottom Bracket |
Sealed cartridge, 73 mm
|
| Pedals |
VP-536 nylon platform
|
| Wheels |
Formula DC20 alloy;Formula DC27 alloy;Bontrager Connection 32-hole double-walled;
|
| Front Tyre |
Bontrager XR2, 29×2.20˝ front, 29×2.0˝ rear (13.5 & 15.5: 27.5×2.20˝)
|
| Rear Tyre |
Bontrager XR2, 29×2.20˝ front, 29×2.0˝ rear (13.5 & 15.5: 27.5×2.20˝)
|
| Saddle |
Bontrager Arvada
|
| Seat Post |
Bontrager alloy, 2-bolt head, 31.6 mm, 12 mm offset
|
| In store Only |
No, Yes
|
| Brand |
Trek
|
